ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting

  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
  • ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting
Plaats van herkomst Sjanghai, China
Merknaam TOBO
Certificering ISO/TUV/SGS
Modelnummer Roestvrij staalelleboog
Min. bestelaantal 1 st
Prijs Onderhandelbaar
Verpakking Details Standaard verzendpakket
Levertijd 15-30 werkdagen
Betalingscondities T/T, Western Union
Levering vermogen 10 ton/maand
Productdetails
Productnaam ASME B16.9 roestvrijstalen stomplas 45 ° elleboog Sch40S pijpfitting Formulier Elmboog, T-shirt, reducer, kap, stub-eind
Schema's Sch.40 aan Sch.XXs Product ss321 ELLEBOOG
Artikelvorm 90 graden elleboog Roestvrij staal H-balk
OEM Geaccepteerd Haven Shanghai, Ningbo, Tianjin
Verbindingstype Met schroefdraad Gebruik oliebranaat industrieel
Dikte 0.1-150 mm Maatbereik 1/2 inch tot 24 inch
Hoek 90 graden Rang 45°, 90°, 180°
Proces Forging+machining+heating Behandeling Oppervlakte van Afwerking Beuken, zandblazen, polijsten
Laat een bericht achter
Productomschrijving

ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting



1. Product Description

The stainless steel butt welding elbow is a fundamental pipe fitting manufactured for changing pipeline direction in permanent welded systems. Produced from high-quality stainless steel coils and bars through hot pressing or cold forming, it features accurately machined bevel ends that ensure rapid and reliable butt welding. The elbow is suitable for a broad spectrum of operating conditions, including general-purpose, corrosive, and high-temperature services. With clean interior surfaces and precise outer dimensions, this product simplifies alignment, reduces welding time, and delivers long-term service reliability.

2. Product Applications

These elbows serve a wide cross-section of industries where welded piping systems are standard:

  • Industrial piping contractors – general plant piping, equipment hook-ups.

  • HVAC and utilities – chilled water, hot water, steam distribution.

  • Fire protection – wet and dry sprinkler systems.

  • Oil depots and tank farms – product transfer and loading lines.

  • Food ingredient plants – edible oil, syrup, and starch processing.

  • Breweries and distilleries – wort, beer, and spirits routing.

  • Cosmetic manufacturing – lotion, cream, and perfume transfer lines.

  • Mining processing plants – tailings, concentrate, and reagent lines.

  • Cement and building materials – slurry and dust suppression systems.

​3. Product Advantages

  • Ready stock on fast-moving sizes – over 200 sizes kept in inventory for immediate dispatch.

  • Grade flexibility – 304/L for general, 316/L for marine/chemical, higher grades on demand.

  • One-piece forming – no welded seams on the elbow body, eliminating a potential weak point.

  • Consistent end squareness – ensures tight butt joints and reduces stress on welds.

  • Clean bore – free from scale, rust, and burrs, ready for installation upon delivery.

  • Clear markings – easy identification on site, reducing installation errors.

  • Affordable pricing – volume production combined with efficient logistics keeps costs low.

  • Quick quotations – respond to inquiries within 2 working hours.

ASME B16.9 Stainless Steel Butt Weld 45° Elbow Sch40S Pipe Fitting 0

4.Key Product Parameters

Parameter Details
Primary Grades 304, 304L, 316, 316L (most commonly stocked)
Secondary Grades 321, 347, 309S, 310S, 904L, 2205 (made to order)
Manufacturing Standards ASME B16.9, GB/T 12459, EN 10253-2, JIS B2313
Stock Sizes (Seamless) DN 15 – DN 400 (NPS ½" – 16")
Stock Sizes (Welded) DN 450 – DN 1200 (NPS 18" – 48")
Stock Wall Thickness SCH 10S, 40S, 80S, STD, XS (most common schedules)
Full Range Wall Thickness SCH 5S through SCH 160, including all intermediate schedules
Radius (Stock) Long radius LR (R=1.5D) for all sizes
Radius (On Request) Short radius SR (R=1.0D), 3D, 5D
Angles (Stock) 45°, 90°
Angles (On Request) 30°, 60°, 180°, custom
Bevel Type Single bevel, 30° ±2°, root face 1.6 mm
Surface (Stock) Pickled and passivated
Surface (Optional) Mechanical polish, mirror finish, sandblasted
Standard Tolerances ASME B16.9 Class 1
Quality Checks 100% visual + dimensional; PMI on random samples
Pressure Ratings Class 150, 300, 600, 900, 1500, 2500
